Adopts Special Inorganic Silicate Material Desiccant Rotor for Lithium Battery

PSC is an energy-saving desiccant rotor specially developed by puresci for the bouble-rotors low dew point dehumidification system .
  • PSC

  • Puresci

Availability:
Quantity:

详情页-PSC_01Puresci focuses on air treatment ,continuously researches and develops new materials and develops new desiccant rotor, and has taken a leading position in the field of dehumidification.Puresci medium regeneration temperature desiccant rotors have been applied to the production of lithium batteries and have achieved significant results. This dehumidification system reduces the regeneration temperature from the traditional 120-140°C(or even higher) to 80-90°C.

Energy saving , Medium regeneration temperature , low dew point double-rotors system

详情页-PST_02详情页-PSS-S_03

Product Details


详情页-PSC_04详情页-PSC_06

Besides standard dimensions (Diameter and Thickness), non-standard rotors can be customized according to customers' requiremens, such as 50mm, 100mm and 150mm.

The bearing can be customized according to customers' requirements if the bearings in the following picture are not your choice.

详情页-PSC_05详情页-PSC_08Material :

The PSC adopts special inorganic sillicate material , and the hydrophilic group adopts special treatment . it is specially designed for low dew point air intake conditions . the soild dehumidification material strenghens the capture function of lower polar water molecules in dry air . the capillary effect is improved ,and the desorption of water does not require too high energy consumption (70-90°C is enough).

0download5                                                                      energy  saving 40%-60%


Change of heating method

Heating

124KW 124KW 124KW 124KW 124KW
Heating method

Electric  heating 0.3Mpa steam heating Hot water boiler Heat pump hot water station Compressor direct expansion system
Dosage

124 kWh/h 0.19t/h 13m³/h 48kwh/h 47kwh/h
unit price 0.8RMB/kwh 280RMB/t 3RMB/m³ 0.8yuan
0.8yuan

37yuan/h
Total price 99RMB/h 53RMB/h 39RMB/h 38yuan/h
generate 77kw of cooling capacity while consuming electricity

The original high-grade energy soures such as electric heating and steam heating are transformed into low-grade heat sources such as hot water boilers (no pressure,no security certification required), condensation heat,and heat transfer oil furnaces.

微信截图_20211109094626


Product Packing and Shipping

详情页-PSS_09Shipping

Via containers by Sea or Air, Or via UPS/ DHL/ FEDEX, Tracking will sent to you via email after samples or goods are shipped out.

Application

REVO详情页-更改版_05Puresci desiccant rotor are widely used in different industries:

Pharmaceutical manufacturing;

Food producing,processing and storing;

Lithium battery and electronic producing;

Ship manufacturing and bridge corrosion resistant;

Plastic and chemical products producing;

Storage and maintenance for military;
